2.6 Terminal unit, IB-583
2-24
2.6 Terminal unit, IB-583
FDD
(For 2HD disk)
Power switch
PRINTER
JUNCTION
(Not provided on IB-583)
DTE
KEYBOARD
LAN (Not provided on
IB-583)
24 VDC power connecter
GND
320
122
270
Fig.2.6.1 Terminal unit, Front and rear views
Fig.2.6.2 Dimensions
