GEH-6641E
—————— Function Description ——————
138
Ch.1
1.14 APPLICATION CARD CONFIGURATION (APPL CARD CONFIG)
1.14.1 Configuration of the DGFC Option Card (DGFC)
The communication between the Drive and the DGFC is performed via two channels for each direction.
· Drive -> DGFC: Drv->DGFCS
5 writing Words - Drv->DGFCA 10 writing Words
As for the Words sending the data from the Drive to the DGFC it is necessary to define the Drive source
parameter.
· DGFC-> Drive: DGFCS->Drv
5 reading Words- DGFCA->Drv 10 reading Words
The Words move the data from the DGFC to the Drive. They can be found in the source selecting lists.
The communication channels are synchronous.
(they are divided into synchronous and asynchronous if the previous software version is taken into consider-
ation. Synchronous channels with 4mS and Asynchronous channels with 16 mS).
DGFC enabling:
DGFC enable it enables the communication initialization of the card at its starting.
If the Drive does not find the DGFC, the “Appl card fault” alarm gets active and
the regulation execution is not started.
For more information to see the following document for related information on DGFC:
GEI 100430 for 6KCV301DGF card
Description:
APPL CARD CONFIG DGFC
DGFC config
DGFC enable
DGFC menu
DGFC sync Ch
Drv->DGFCS W src
Drv DGFC-S W0src
Drv DGFC-S W1src
Drv DGFC-S W2src
Drv DGFC-S W3src
Drv DGFC-S W4src
Drv->DGFCS W cfg
Int DrvDGFC-S W0
Int DrvDGFC-S W1
Int DrvDGFC-S W2
Int DrvDGFC-S W3
Int DrvDGFC-S W4
Drv->DGFCS W mon
Drv DGFC-S W0mon
Drv DGFC-S W1mon
