AV-300i Version 2 User’s Guide
—————— Block Diagrams ——————
Ch.2
197
AV-300i AC flux vector Drive
10/15/99 -- RM
File name:
Issued Date
Initials:
Revision Date
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
GE Industrial Systems
Salem, Va. USA
Proprietary Information
Do Not Copy
PRODUCT:
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
ABCDEFGH I J K LMNOPQRST U
ABCDEFGH I J K L
Control
Back
NAVIGATION
03/02/00 -- RNC
Power loss stop / Ride through control
AC Mains voltage
100 %
100 %
DC link voltage
PL Timer
Speed ref
Actual speed
Torque current
+100 %
-100 %
Power loss detection
UV level detection
PI regulator
time
Speed ratio
calculator
To Analog input set
as "Speed ratio" of
Next Drive
Pwr_loss_ctrl.vsd
PI regulator
P2280
P2270
Current Limit
Power Loss Ctrl
Torque curr ref
Power Ride Thru
Stop
Stop
Stop
Ride through
Ride through
Ride through
Ride through
DC link voltage
PLS Vdc ref
736,307 V
Norm Speed
PLS timeout
10 s
PL deceleration
10000 rpm/s
PL acceleration
100 rpm/s
Speed ref
PLS curr lim
0,896209 A
DC link voltage
PLS I gain
3,28381 A/V/s
PLS P gain
0,0492572 A/V
PLS Vdc ref
736,307 V
Norm Speed
Speed ref
PLS active
PL next active
PL next factor
DC link voltage
PLS mains st src
NULL
PL function sel
Off
