GE AV-300I User Manual

GEH-6641E
—————— Function Description ——————
46
Ch.1
Curr regulator Current loop
Percent values
percentage values:
CurrP gain % Gain of the Proportional section as a percentage of the basic value
CurrI gain % Gain of the Integral section as a percentage of the basic value
Base values
basic values:
CurrP base value Basic value of the Proportional gain
CurrI base value Basic value of the Integral gain
Flux regulator Flux loop
Percent values
percentage values:
FlxP gain % Gain of the Proportional section as a percentage of the basic value
FlxI gain % Gain of the Integral section as a percentage of the basic value
Base values
basic values:
FlxP base value Basic value of the Proportional gain
FlxI base value Basic value of the Integral gain
Vlt regulator Speed loop
Percent values
percentage values:
VltP gain % Gain of the Proportional section as a percentage of the basic value
VltI gain % Gain of the Integral section as a percentage of the basic value
Base values
basic values:
VltP base value Basic value of the Proportional gain
VltI base value Basic value of the Integral gain
REGULATION PARAM SAVE PARAMETERS
1.4.2 Dead Time Comp
The Dead time comp function allows for compensation of the output voltage distortion due to IGBT voltage
drop and its switching characteristics. Distortion of output voltage may cause non uniform, non smooth shaft
rotation in open loop V/f control or in a closed loop Sensorless Vector control mode errors in speed estimation
especially at very low speeds.Through the two parameters it is possible to set a voltage value and the compen-
sation variation, called Gradient.
Description:
REGULATION PARAM
Dead time comp
Dead time limit Value of the voltage compensation
Dead time slope Compensation Gradient
REGULATION PARAM SAVE PARAMETERS
NOTE! Both parameters are automatically measured during CurrReg autotune procedure.
