GEH-6641E
—————— Parameters & Pick Lists ——————
270
Ch.3
3.2 NUMERIC ORDER PARAMETERS LIST
3.2.1 Numeric Order Parameter List Caption
Ipa Parameter number.
Index used to enter the parameter via the serial line or the option cards.
Point type
It states the point type.
The format is the following: $AB or $pin
$AB
$ internal identification key
A can to be > P float type
> D digital type (Integer with 16 bits)
B can to be > P parameter
> V variable
> K constant
$PIN
the parameter type is enumerative. It has, therefore, a list of pos-
sible values (for example it is a source).
Validity DB
It states the regulation mode in which the parameter is valid.
The reading keys are:
F Field oriented
S Sensorless
V V/f
A Autotuning (Setup mode)
B internal use
Description
Description of the parameter shown on the display.
