AV-300i Version 2 User’s Guide
—————— Function Description ——————
Ch.1
63
Table 1.5.3.1-1: Setup for Control from Keyboard (Factory Setup)
Parameter description Index Value Comments
Command select 4002 Stop/FS & Spd=0
En/Disable mode 4004 I O keys
Dig Enable src 0156 Do not care This source bypassed (AND logic)
Term StrStp src 0153 "DI 1 mon" This source bypassed (AND logic)
Dig StrStp src 0157 Do not care This source not used
Term Start src 9210 Do not care This source not used
Term Stop src 9211 Do not care This source not used
FStop src 0154 "NULL" Fast stop not used
Jog cmd src 8015 "NULL" Jog from the keyboard
Jog invers src 8018 "NULL" Jog inversion from the keyboard
Spd 0 dis dly 4006 1000 msec
Spd 0 speed thr 3724 10 rpm
TAV35311
1.5.3.2 Control from Remote Pushbuttons
Command select = "Terminal edge"
This setup is useful for simple, standalone istallations where no PLC is used and the external relay logic is
minimal.
The keyboard/display module is not required, a LED module can be used instead. Momentary action pushbuttons
are used for Start, Stop, Jog and Jog inversion, with the mandatory Terminal Enable permissive.
En/Disable control logic and Jog are active.
No input is set for Fast stop command.
Parameters can be set as per example in table 1.5.3.2-1.
Complete wiring information for digital inputs may be found in the hardware reference section. The drive behaviour
is similar to the one for keyboard control (sect. 1.5.3.3.1), but for the fact that the four remote wired pushbuttons
replace the corresponding keys on the keyboard.
Of course there is no need to use a [Shift] button as remote buttons do not have multiple functions.
Table 1.5.3.2-1: Example Setup for Pushbutton Control
Parameter description Index Value Comments
Command select 4002 Terminal edge
En/Disable mode 4004 Stop/FS & Spd=0
Dig Enable src 0156 Do not care This source bypassed (AND logic)
Term StrStp src 0153 "NULL" This source bypassed (AND logic)
Dig StrStp src 0157 Do not care This source not used
Term Start src 9210 "DI 1 monitor" Tie Start button to terminal 13
Term Stop src 9211 "DI 2 monitor" Tie Stop button to terminal 14
FStop src 0154 "NULL" Fast stop not used
Jog cmd src 8015 "DI 3 monitor" Tie Jog button to terminal 15 (Jog used)
Jog invers src 8018 "DI 4 monitor"
Tie Jog invert button to terminal 36 (Jog used)
TAV35321
