GE AV-300I User Manual

GEH-6641E
—————— Parameters & Pick Lists ——————
252
Ch.3
3.1.3.1 Setup Mode Menu
Following menu will be activated by: STARTUP / Startup config / Enter setup mode
Startup config
Enter setup mode [c] the drive will reboot to SETUP MODE
Drive data > Drive parameters
Mains voltage > Main voltage
Ambient temp > Ambient temp
Switching freq > PWM switching
Spd ref/fbk res > Speed resolution
Motor data > Motor parameters
Rated voltage
Rated frequency
Rated current
Rated speed
Rated power
Cosfi > Motor cosphi
Efficiency > Motor efficiency
Load default mot > Load default motor
Standard 400V
Standard 460V
CurrReg autotune > CurrentRegulator measurament
Start ? > Enable procedure
Results > Measurament results
Measured Rs > Stator resistance
Measured Rr > Rotor resistance
Measured Rr2 > Rotor resistance2
Measured DTs > Dead time limit
Measured DTL > Dead time slope
Measured LsSigma > Statoric inductance
FluxReg autotune > FluxRegulator measurament
Shaft rotating > with moving Rotor
Start ? > Enable procedure
Results > Measurament results
Measured P1 flux > P1 coeff. of flux curve
Measured P2 flux > P2 coeff. of flux curve
Measured P3 flux > P3 coeff. of flux curve
Measured ImNom > value of the Rated magn. Curr.
Measured ImMax > value of the Max magn. Curr.
Measured FluxNom > value of the Rated Flux
Measured FluxMax > value of the Max Flux
At standstill > with stopped Rotor
Start ?
Save setup > Save of the set and detected data
Save as? > allows to select 4 files where 4 different motor setups can be saved
Setup 0 > motor setup File0
Setup 1 > motor setup File1
Setup 2 > motor setup File2
Setup 3 > motor setup File3
Review setup > Recall saved setup files command
Exit setup mode > Exit Setup Mode command
the drive will reboot to STATUS menu
STARTUP
SETUP MODE
