GE AV-300I User Manual

GEH-6641E
—————— Parameters & Pick Lists ——————
232
Ch.3
3.1.2 Menu
Pick-list V/F FOC SLS
3060 Output voltage
vvv
3070 Output current
vvv
3090 Output power
vvv
2450 Torque ref N/A
vv
3080 Output frequency
vvv
3221 Norm Speed
vvv
3210 Speed ref
vvv
3200 Ramp ref
vvv
162 Enable SM mon
vvv
163 Start SM mon
vvv
164 FastStop SM mon
I/O status
vvv
4028 DI 7654321E
vvv
4064 DO 3210
vvv
4057 DIX BA9876543210
vvv
4078 DOX 76543210
vvv
Advanced Status
3100 DC link voltage
vvv
3110 Magnetizing curr
vvv
3120 Torque curr
vvv
3130 Magn curr ref N/A
vv
3140 Torque curr ref N/A
vv
3180 Flux ref N/A
vv
3190 Flux N/A
vv
1670 Mot OL accum %
vvv
1781 BU OL accum %
vvv
1540 Drv OL accum %
vvv
3222 Norm Std enc spd
vvv
3223 Norm Exp enc spd
vv
N/A
9553 Std enc position N/A
v
N/A
9554 Exp enc position N/A
v
N/A
9555 Std sin enc mod N/A
v
N/A
9072 HT sensor temp
vvv
9073 RG sensor temp
vvv
9095 IA sensor temp
vvv
9090 Sequencer status
vvv
3230 CPU1 runtime
vvv
3240 CPU2 runtime
vvv
Drive ID status
1460 Drive cont curr
vvv
114 Drive size
vvv
300 Drive type
vvv
115 Drive name
vvv
810 Actual setup
vvv
Software version V .
110 Software type
vvv
111 Software status
vvv
99 Life time
vvv
98 Sys time-ddmmyy
vvv
Alarm log N/A N/A N/A
Pick-list V/F FOC SLS
Regulation mode
Select new mode
vvv
100 Regulation mode
Startup config
Enter setup mode [c] -> The drive will reboot to SETUP MODE (see chapter 3.1.2.1)
Load setup
Select setup ?
Full scale speed
1885 Full scale speed
vvv
Encoders config
Speed feedback
1940 Int spd fbk sel
vv
N/A
7058 Spd fbk sel src List 22
v
N/A N/A
1925 Std enc type
vvv
1890 Std enc pulses
vvv
1931 Std dig enc mode
vvv
1927 Std enc supply
vvv
STATUS
STARTUP
