AV-300i Version 2 User’s Guide
—————— Function Description ——————
Ch.1
39
Save config ?
BU control BU control. Off, Internal, External
BU resistance BU Braking resistance
BU res cont pwr Resistance continuos power
BU res OL factor BU allowed overload factor referring to the overload power of the braking resistance
BU res OL time Resistance allowed overload time referring to the overload Power
The control of the external braking unit and of the resistance I
2
t protection is indipendent of BU type (BU digital
output command, comm output, on the regulation card).
1.3.2.9 In General
Load default ? Drive reset with default data
Abort ? Reload of the last saved database. The data set after the saving process are not
stored. It is advisable to carry out a save config before entering the start up menu.
Save config ? It saves the database. It is advisable to carry out a save config after leaving the
start up menu.
1.3.3 Recipes - Import Recipe & Export Recipe
A recipe is a file where a bank of setup information can be written (Export) or read (Import)between regulation
modes. Such information includes:
· Parameter index, Value.
The recipe use allows to move a parameter set among the different regulation modes or among different Drives
via the PC Configurator.
The recipes present on the drive are:
· I/O config See the excel sheet: I_O config Recipe
· Ramp & speed cfg Ramp _ speed config Recipe
· Appl function Appl function Appl card & comm Recipe Appl card _ comm Recipe
· User 5 Not used
· User 6 Not used
· User 7 Not used
Description:
STARTUP
Import recipe
Select recipe:
Export recipe
Select recipe:
Save config ?
Import recipe
Select recipe: It imports (reads) the data of the recipe
Export recipe
Select recipe: It exports (writes) the data of the recipe
