AV-300i Version 2 User’s Guide
—————— Parameters & Pick Lists ——————
Ch.3
265
V/F FOC SLS V/F FOC SLS V/F FOC SLS
DC link voltage 3100 v v v
Magnetizing curr 3110 v v v
Torque curr 3120 v v v
Magn curr ref 3130 N/A v v
Torque curr ref 3140 N/A v v
Current phase U 3150 v v v
Current phase V 3160 v v v
Current phase W 3170 v v v
Flux ref 3180 N/A v v
Flux 3190 N/A v v
Ramp ref 3200 v v v
Speed ref 3210 v v v
Speed 3220 v v v
Norm Speed 3221 v v v
Fault Pin 9098 v v v
Norm Std enc spd 3222 v v v
Norm Exp enc spd 3223 v v N/A
Drv OL accum % 1540 v v v
Mot OL accum % 1670 v v v
BU OL accum % 1781 v v v
NULL 4000 v v v
ONE 4001 v v v
Gen output 2760 v v v
An inp 1 output 5009 v v v
An inp 2 output 5029 v v v
An inp 3 output 5049 v v v
An inp 1X output 5067 v v v
An inp 2X output 5087 v v v
W0 comp out 2116 v v v
W1 comp out 9356 v v v
SBI Drv W0 mon 9000 v v v
SBI Drv W1 mon 9001 v v v
SBI Drv W2 mon 9002 v v v
SBI Drv W3 mon 9003 v v v
SBI Drv W4 mon 9004 v v v
SBI Drv W5 mon 9005 v v v
ISBus Drv W0 mon 9300 v v v
ISBus Drv W1 mon 9301 v v v
ISBus Drv W2 mon 9302 v v v
ISBus Drv W3 mon 9303 v v v
ISBus Drv W4 mon 9304 v v v
ISBus Drv W5 mon 9305 v v v
ISBus Drv W6 mon 9306 v v v
ISBus Drv W7 mon 9307 v v v
DGFC-S Drv W0mon 4120 v v v
DGFC-S Drv W1mon 4121 v v v
DGFC-S Drv W2mon 4122 v v v
DGFC-S Drv W3mon 4123 v v v
DGFC-S Drv W4mon 4124 v v v
DGFC-A Drv W0mon 4160 v v v
DGFC-A Drv W1mon 4161 v v v
DGFC-A Drv W2mon 4162 v v v
DGFC-A Drv W3mon 4163 v v v
DGFC-A Drv W4mon 4164 v v v
DGFC-A Drv W5mon 4165 v v v
DGFC-A Drv W6mon 4166 v v v
DGFC-A Drv W7mon 4167 v v v
DGFC-A Drv W8mon 4168 v v v
DGFC-A Drv W9mon 4169 v v v
PID FF mon 7217 v v v
PID input 7256 v v v
PID PI out mon 7294 v v v
Last PI out 7295 v v v
PID PD out mon 7343 v v v
PID out mon 7352 v v v
PID outS mon 7353 v v v
Pad 0 9100 v v v
Pad 1 9101 v v v
Pad 2 9102 v v v
Pad 3 9103 v v v
Pad 4 9104 v v v
Pad 5 9105 v v v
Pad 6 9106 v v v
Pad 7 9107 v v v
Pad 8 9108 v v v
Pad 9 9109 v v v
Pad 10 9110 v v v
Pad 11 9111 v v v
Pad 12 9112 v v v
Pad 13 9113 v v v
Pad 14 9114 v v v
Pad 15 9115 v v v
Pick List 33
Int PID draw 7231 v v v
Output voltage 3060 v v v
Output current 3070 v v v
Output frequency 3080 v v v
Output power 3090 v v v
DC link voltage 3100 v v v
Magnetizing curr 3110 v v v
Torque curr 3120 v v v
Magn curr ref 3130 N/A v v
Torque curr ref 3140 N/A v v
Current phase U 3150 v v v
Current phase V 3160 v v v
Current phase W 3170 v v v
Flux ref 3180 N/A v v
Flux 3190 N/A v v
Ramp ref 3200 v v v
Speed ref 3210 v v v
Speed 3220 v v v
Norm Speed 3221 v v v
Fault Pin 9098 v v v
Norm Std enc spd 3222 v v v
Norm Exp enc spd 3223 v v N/A
Drv OL accum % 1540 v v v
Mot OL accum % 1670 v v v
BU OL accum % 1781 v v v
NULL 4000 v v v
ONE 4001 v v v
Gen output 2760 v v v
An inp 1 output 5009 v v v
An inp 2 output 5029 v v v
An inp 3 output 5049 v v v
An inp 1X output 5067 v v v
An inp 2X output 5087 v v v
W0 comp out 2116 v v v
W1 comp out 9356 v v v
SBI Drv W0 mon 9000 v v v
SBI Drv W1 mon 9001 v v v
SBI Drv W2 mon 9002 v v v
SBI Drv W3 mon 9003 v v v
SBI Drv W4 mon 9004 v v v
SBI Drv W5 mon 9005 v v v
ISBus Drv W0 mon 9300 v v v
ISBus Drv W1 mon 9301 v v v
ISBus Drv W2 mon 9302 v v v
ISBus Drv W3 mon 9303 v v v
ISBus Drv W4 mon 9304 v v v
ISBus Drv W5 mon 9305 v v v
ISBus Drv W6 mon 9306 v v v
ISBus Drv W7 mon 9307 v v v
DGFC-S Drv W0mon 4120 v v v
DGFC-S Drv W1mon 4121 v v v
DGFC-S Drv W2mon 4122 v v v
DGFC-S Drv W3mon 4123 v v v
DGFC-S Drv W4mon 4124 v v v
DGFC-A Drv W0mon 4160 v v v
DGFC-A Drv W1mon 4161 v v v
DGFC-A Drv W2mon 4162 v v v
DGFC-A Drv W3mon 4163 v v v
DGFC-A Drv W4mon 4164 v v v
DGFC-A Drv W5mon 4165 v v v
DGFC-A Drv W6mon 4166 v v v
DGFC-A Drv W7mon 4167 v v v
DGFC-A Drv W8mon 4168 v v v
DGFC-A Drv W9mon 4169 v v v
PID FF mon 7217 v v v
PID input 7256 v v v
PID PI out mon 7294 v v v
Last PI out 7295 v v v
PID PD out mon 7343 v v v
PID out mon 7352 v v v
PID outS mon 7353 v v v
Pad 0 9100 v v v
Pad 1 9101 v v v
Pad 2 9102 v v v
Pad 3 9103 v v v
Pad 4 9104 v v v
Pad 5 9105 v v v
Pad 6 9106 v v v
Pad 7 9107 v v v
Pad 8 9108 v v v
Pad 9 9109 v v v
Pad 10 9110 v v v
Pad 11 9111 v v v
Pad 12 9112 v v v
Pad 13 9113 v v v
Pad 14 9114 v v v
Pad 15 9115 v v v
Pick List 34
Int PID set 0 7232 v v v
Output voltage 3060 v v v
Output current 3070 v v v
Output frequency 3080 v v v
Output power 3090 v v v
DC link voltage 3100 v v v
Magnetizing curr 3110 v v v
Torque curr 3120 v v v
Magn curr ref 3130 N/A v v
Torque curr ref 3140 N/A v v
Current phase U 3150 v v v
Current phase V 3160 v v v
Current phase W 3170 v v v
Flux ref 3180 N/A v v
Flux 3190 N/A v v
Ramp ref 3200 v v v
Speed ref 3210 v v v
Speed 3220 v v v
Norm Speed 3221 v v v
Fault Pin 9098 v v v
Norm Std enc spd 3222 v v v
Norm Exp enc spd 3223 v v N/A
Drv OL accum % 1540 v v v
Mot OL accum % 1670 v v v
BU OL accum % 1781 v v v
NULL 4000 v v v
ONE 4001 v v v
Gen output 2760 v v v
An inp 1 output 5009 v v v
An inp 2 output 5029 v v v
An inp 3 output 5049 v v v
An inp 1X output 5067 v v v
An inp 2X output 5087 v v v
W0 comp out 2116 v v v
W1 comp out 9356 v v v
SBI Drv W0 mon 9000 v v v
SBI Drv W1 mon 9001 v v v
SBI Drv W2 mon 9002 v v v
SBI Drv W3 mon 9003 v v v
SBI Drv W4 mon 9004 v v v
SBI Drv W5 mon 9005 v v v
