Defining the System Setup: Define the Exercise Test Setup (Option)
14-26 MAC 5000 System — 2000657-057, Revision B
12 and 15 Lead Exercise Reports
Select this function to:
n
Identify the three auxiliary leads used to acquire a 15
lead exercise ECG using the 15 lead ECG function
(option).
n
Specify the leads displayed on exercise reports.
Extra Leads (15 Lead ECG Option Only)
Report Leads
Item Description
Lead Set Choose the three additional leads used. You can:
n
select one of the pre-defined lead sets, or
n
select Custom 3 to define the electrode positions of
A1, A2, and A3.
System Setup
Exercise Test
Exercise Test
12 Lead Exercise
15 Lead Exercise
168A, 215A
Item Description
Standard leads Select the standard leads you want to appear on the
ECG reports.
áWhen you change a channel’s lead, the new lead
appears on all the ECG reports displaying that
channel.
Rhythm reports Choose the type of data displayed in the Rhythm
reports.
n
Select Real time to print current ECG data on the
Rhythm reports. This allows you to print the data
you see on the screen.
n
Select 10 sec delayed to print ECG data delayed by
10 seconds.
