GE MAC 5000 Operator's Manual

Defining the System Setup: Define the Exercise Test Setup (Option)
14-28 MAC 5000 System — 2000657-057, Revision B
Exercise Reports
Allows you to choose the report you wish to print with the
12-lead or optional 15-lead exercise tests.
Final Report
Use the Reports function to set up the types of reports you
want to print with the final report. These reports print
during the TEST-END phase.
Item Description
Storage Option Select Store strips and final report, Store final report
only, or No storage of test data to store in-test strips or
final reports to diskette.
Final Report
Preview
Select No Preview Report, Summary Report, Tabular
Report, Selected Medians, Trend & Medians, Median
Report, or Trend Report format to print as a preview
report before Reason for Termination and Comments
are entered and all final reports are printed at test end.
System Setup
Exercise Test
Exercise Test
Final Report
168A, 057A
Summary Report Enter the number of copies to be printed. Select either
Resting and Max ST Medians or Resting and Peak
Exercise Medians format for the final summary report.
Tabular Report Enter the number of copies to be printed.
Selected
Medians
Enter the number of copies to be printed.
Trend & Medians Enter the number of copies to be printed.
Median Report
Leads
Enter the number of copies to be printed. Then, select
either 3, 6, or All leads for the median report. All
means that the report has either 12 or 15 leads.
Fifteen leads appear only if extra leads — such as X,
Y, or Z — were chosen in Basic System setup.
Trend Report
Leads
Enter the number of copies to be printed. Then, select
either 3 or All leads for the trend report.
ST-HR Loops Enter the number of copies to be printed.
ST/HR Report Enter the number of copies to be printed for the ST/
Heart Rate Slope report.
Item Description
