GE MAC 5000 Operator's Manual

Appendix D – Technical Specifications: Writer
MAC 5000 System — 2000657-057, Revision B D-11
Writer
Item Description
Type Thermal dot array (horizontal 1000 dots/in at 25 mm/s; vertical 200 dots/in)
Frequency Response 0.01 to 150 Hz
Number of Traces 3, 6, 12, 15 user-selectable and programmable (same as display)
Paper Speeds 5, 12.5, 25, 50 mm/s DC drive
Sensitivity/Gain 2.5, 5, 10, 20, and 10/5 (split calibration) mm/mV
Speed/Sensitivity Accuracy ± 2%
Sensitivity (Gain) Accuracy ± 5%
Paper Type Thermal, perforated, 214.63 mm x 280 mm (8.45 in x 11 in), z-fold, 300 sheets per pack (European 210 mm x 297.5 mm
(8.27 in x 11.7 in) A4 style paper available)
