Appendix E – Report Formats: Format Description
E-8 MAC 5000 System — 2000657-057, Revision B
Exercise Final Report Names
Report Name Description
Summary Report One page overview of test with Resting and Max ST or peak median morphologies. For Maximal ST Depression, report only
prints when a minimum of -.5 mm of ST depression occurs in one of the following leads. I, II, III, aVF, V2-V6. (V1, aVR, aVL
excluded. For elevation, - aVR is excluded).
Tabular Report Tabular summary of test by stage including time, speed, grade, workload, MET level, heart rate, blood pressure, RPP and
comments.
Selected Medians Report Records median morphologies at Baseline, Maximum ST Depression, Peak Exercise and Test End for 12 leads. For
Maximum ST medians, column only prints when a minimum of -.5 mm of ST depression occurs in one of the following leads.
I, II, III, aVF, V2-V6. (V1, aVR, aVL excluded. For elevation, - aVR is excluded).
Trends and Medians Records a plot of the heart rate and blood pressure against time. Next to these trend graphs are channels of stored median
data from the various stages of an exercise test.
Median Report Records median morphologies for 3, 6 or 12 leads. The 3 and 6 lead reports are configured using the ’Swedish format
rhythm leads’ of the Exercise Setups (Report Leads). The 12 lead report uses the standard 12 lead set. The median storage
intervals (also referred to as sample cardiac cycles) can be configured using the Median (First and Repeat) column of the
Protocol Editor.
Trend Reports Records plots of PVCs, heart rate and blood pressure. Also produces trend report of ST level and slope vs. time. The 3-lead
trend report will use the first three leads of the ‘Swedish format rhythm leads’.
ST/HR Loops Report A two-dimensional representation of ST Level vs. Heart Rate.
ST/HR Slope Report Records linear regression of heart rate-adjusted slope for all leads, plus median morphology of lead with highest slope.
