Appendix E – Report Formats: Format Description
MAC 5000 System — 2000657-057, Revision B E-5
Additional Report Names
Report Name Description
12 Rhythm Leads 10 seconds of 12-lead rhythm.
Autorhythm 10 seconds of 3, 6, or 12 leads of rhythm.
CGR One median complex for each of the 12 leads combined with 10 seconds of 3-lead rhythm.
Expanded Median Each median complex can be expanded by double the speed and double the gain.
Linked Median A 4 x 2.5 with 1 rhythm lead format. Each lead begins with a median waveform and is followed by real-time data. The
rhythm lead printed across the bottom of the report is the first lead of the ’Swedish format rhythm leads’ group that is
configured in Exercise Setups (Report Leads).
Medians and Rhythm A median complex for each of the standard 12 leads is displayed in the upper portion of this report. Below the medians are
three rhythm strips. These rhythm leads are the first three leads of the ’Swedish format rhythm leads’ group that is
configured in Exercise Setups (Report Leads).
6 Lead Comparative
Medians and Rhythm
The baseline and current medians are compared side-by-side and followed by real-time waveforms. The 6 leads used by
this report are the ’Swedish format rhythm leads’ group that is configured in Exercise Setups (Report Leads).
12 Lead Comparative
Medians and Rhythm
A one-page report for which the baseline and current medians are compared side-by-side and followed by 2.5 seconds of
real-time rhythm for the standard 12 leads. ST level and ST slope are reported for each lead.
Hi-Res or PHi-Res Signal
Averaged Template
Dominant (averaged) beat type.
Hi-Res or PHi-Res Signal
Averaged Standard
Vector magnitudes of X,Y,Z.
Hi-Res or PHi-Res Signal
Averaged Expanded
400mm/s of expanded X,Y,Z medians and a RMS voltage function/VM plot.
ACI-TIPI The analysis of the acquired ECG data appears at the top of the report.
