GE Power Quality Meter Series User Manual

GE Power Management PQM Power Quality Meter 4-45
4 PROGRAMMING 4.5 S4 ALARMS/CONTROL
4
4.5.5 POWER FACTOR
Figure 4–28: SETPOINTS PAGE 4 – ALARMS/CONTROL / POWER FACTOR
]] SETPOINTS
]] S4 ALARMS/CONTROL
] POWER FACTOR
]
POWER FACTOR LEAD 1
RELAY: OFF
POWER FACTOR LEAD 1
PICKUP
≤
≤≤
≤ 0.99
POWER FACTOR LEAD 1
DROPOUT
≥
≥≥
≥ 1.00
]] SETPOINTS
]] S5 TESTING
SETPOINT
Range: ALARM, AUX1, AUX2, AUX3, OFF
POWER FACTOR LEAD 1
DELAY: 10.0 s
POWER FACTOR LAG 1
RELAY: OFF
POWER FACTOR LAG 1
PICKUP ≤
≤≤
≤ 0.99
Range: 0.5 to 600.0; Step 0.5 s
Range: ALARM, AUX1, AUX2,
AUX3, OFF
POWER FACTOR LAG 1
DROPOUT
≥
≥≥
≥ 1.00
POWER FACTOR LAG 1
DELAY: 10.0 s
Range: 0.50 to 1.00, Step 0.01
Range: 0.50 to 1.00, Step 0.01
POWER FACTOR LEAD 2
RELAY: OFF
POWER FACTOR LEAD 2
PICKUP ≤
≤≤
≤ 0.99
POWER FACTOR LEAD 2
DROPOUT ≥
≥≥
≥ 1.00
POWER FACTOR LEAD 2
DELAY: 10.0 s
POWER FACTOR LAG 2
RELAY: OFF
POWER FACTOR LAG 2
PICKUP
≤
≤≤
≤ 0.99
POWER FACTOR LAG 2
DROPOUT ≥
≥≥
≥ 1.00
POWER FACTOR LAG 2
DELAY: 10.0 s
Range: 0.50 to 1.00, Step 0.01
Range: 0.50 to 1.00, Step 0.01
Range: 0.5 to 600.0; Step 0.5 s
Range: ALARM, AUX1, AUX2,
AUX3, OFF
Range: 0.50 to 1.00, Step 0.01
Range: 0.50 to 1.00, Step 0.01
Range: 0.5 to 600.0; Step 0.5 s
Range: ALARM, AUX1, AUX2,
AUX3, OFF
Range: 0.50 to 1.00, Step 0.01
Range: 0.50 to 1.00, Step 0.01
Range: 0.5 to 600.0; Step 0.5 s
MESSAGE
MESSAGE
MESSAGE
