GE Power Quality Meter Series User Manual

4-52 PQM Power Quality Meter GE Power Management
4.5 S4 ALARMS/CONTROL 4 PROGRAMMING
4
4.5.8 TIME
Figure 4–32: SETPOINTS PAGE 4 – ALARMS/CONTROL / TIME
The time function is useful where a general purpose time alarm is required or a process is required to start and
stop each day at the specified time.
•
TIME RELAY
: This setpoint can be used to give an indication (alarm or control) if the programmed
PICKUP
TIME
is equaled or exceeded. Set to
OFF
if the feature is not required. Selecting
ALARM
activates the alarm
relay and displays an alarm message whenever the PQM clock time equals or exceeds the set
PICKUP
TIME
. Selecting
AUX1
,
AUX2
or
AUX3
activates the appropriate auxiliary relay but no message is displayed.
The
AUX1
,
AUX2
and
AUX3
selections are intended for process control. The selected relay will de-energize
when the PQM clock time equals or exceeds the
DROPOUT TIME
setting.
•
PICKUP TIME
: The relay assigned in the
TIME RELAY
setpoint energizes when the PQM clock time equals
or exceeds the time specified in this setpoint. Follow the example below to set the
PICKUP TIME
.
•
DROPOUT TIME
: The relay assigned in the
TIME RELAY
setpoint de-energizes when the PQM clock time
equals or exceeds the time specified in this setpoint. Follow the example above to set the
DROPOUT TIME
.
]] SETPOINTS
]] S4 ALARMS/CONTROL
] TIME
]
TIME
RELAY: OFF
PICKUP TIME ≥
≥≥
≥
12:00:00 am
DROPOUT TIME ≥
≥≥
≥
12:00:00 pm
]] SETPOINTS
]] S5 TESTING
SETPOINT
Range: ALARM, AUX1, AUX2, AUX3, OFF
Range: hh:mm:ss am/pm
Range: hh:mm:ss am/pm
MESSAGE
MESSAGE
MESSAGE
PICKUP TIME ≥
≥≥
≥
12:00:00 am
PICKUP TIME ≥
≥≥
≥
03:00:00 am
PICKUP TIME ≥
≥≥
≥
03:35:00 am
MESSAGE
PICKUP TIME ≥
≥≥
≥
03:35:55 am
NEW SETPOINT
STORED
MESSAGE
MESSAGE
STORE
VALUE
USE THE VALUE
KEYS TO SELECT THE
UNDERLINED
QUANTITIES
