GE Power Management PQM Power Quality Meter 8-5
8 DNP COMMUNICATIONS 8.1 DNP 3.0 PROTOCOL
8
8.1.5 BINARY INPUT / BINARY INPUT CHANGE POINT LIST
POINT LIST FOR: BINARY INPUT (OBJECT 01) / BINARY INPUT CHANGE (OBJECT 02)
INDEX DESCRIPTION EVENT CLASS
ASSIGNED TO
NOTES
0 Alarm condition(s) active Class 1
1 Clock not set Class 1 Note 1
2 Clock drifting Class 1
3 Internal error: ADC reference out of range Class 1
4 Internal error: HC705 processor not responding Class 1
5 Internal error: switch input circuit fault Class 1
6 PQM (display) option installed Class 1
7 T20 (4-20 mA transducer) option installed Class 1
8 T1 (0-1 mA transducer) option installed Class 1
9 C (control) option installed Class 1
10 A (power analysis) option installed Class 1
11 Switch A closed Class 1
12 Switch B closed Class 1
13 Switch C closed Class 1
14 Switch D closed Class 1
15 Alarm relay energized Class 1
16 Auxiliary relay 1 energized Class 1
17 Auxiliary relay 2 energized Class 1
18 Auxiliary relay 3 energized Class 1
19 Aux 1 relay LED active Class 1
20 Aux 2 relay LED active Class 1
21 Aux 3 relay LED active Class 1
22 Alarm LED active Class 1
23 Program LED active Class 1
24 Simulation LED active Class 1
25 Alarm relay LED active Class 1
26 Self test LED active Class 1
27 Aux 1 relay LED solid (not flashing) Class 1
28 Aux 2 relay LED solid (not flashing) Class 1
29 Aux 3 relay LED solid (not flashing) Class 1
30 Alarm LED solid (not flashing) Class 1
31 Program LED solid (not flashing) Class 1
32 Simulation LED solid (not flashing) Class 1
33 Alarm relay LED solid (not flashing) Class 1
34 Self test LED solid (not flashing) Class 1
35 Alarm active: phase undercurrent Class 1
36 Alarm active: phase overcurrent Class 1
37 Alarm active: neutral overcurrent Class 1
38 Alarm active: undervoltage Class 1
39 Alarm active: overvoltage Class 1
40 Alarm active: current unbalance Class 1
Note 1: This point is also reflected in the corresponding internal indication (IIN) bit in each response header.
