8-14 PQM Power Quality Meter GE Power Management

8.1 DNP 3.0 PROTOCOL 8 DNP COMMUNICATIONS

8.1.8 POINT LIST FOR COUNTERS

Only counter points 0 to 4 can be cleared using function codes 9 and 10, and doing so disturbs the

totals presented on the display and via Modbus communications. In general, the binary output points

which clear data should be used if it is necessary to clear any of these counters.

Point list for: Binary Counters (object 20)

Frozen Counters (object 21)

Counter Change Event (object 22)

Frozen Counter Events (object 23)

Point

Num

Modbus

Description Unit Deadband Format

code

Event class point

assigned to

0 0450 Pulse Input 1 - - F3 -

1 0452 Pulse Input 2 - - F3 -

2 0454 Pulse Input 3 - - F3 -

3 0456 Pulse Input 4 - - F3 -

4 0460 Totalized Pulse Input - - F3 -

5 03D0 3 Phase Positive Real Energy

Used

kWh - F3 -

6 03D2 3 Phase Negative Real Energy

Used

kWh - F3 -

7 03D4 3 Phase Positive React.

Energy Used

kvarh - F3 -

8 03D6 3 Phase Negative React.

Energy Used

kvarh - F3 -

9 03D8 3 Phase Apparent Energy

Used

kVAh - F3 -

10 03DA 3 Phase Energy Used in Last

24 h

kWh - F3 -

11 03DC 3 Phase Energy Cost Since

Reset

cents - F3 -

12 03DE 3 Phase Energy Cost Per Day cents - F3 -

NOTE
