GE Power Quality Meter Series User Manual

GE Power Management PQM Power Quality Meter 4-57
4 PROGRAMMING 4.6 S5 TESTING
4
4.6.4 ANALOG INPUT SIMULATION
Figure 4–37: SETPOINTS PAGE 5 – ANALOG INPUT SIMULATION
•
SIMULATION
: Enter
ON
to switch from an actual analog input to the programmed simulated value. Set this
setpoint
OFF
after simulation is complete.
•
SIMULATION ENABLED FOR
: Select the desired length of time that simulation will be enabled. When the
programmed time has elapsed, analog input simulation will turn off. If unlimited is selected, the simulated
analog input will be used until simulation is turned off via the
SIMULATION
setpoint or via the serial port or
until control power is removed from the PQM.
•
ANALOG INPUT
: Enter an analog input current in the range of 4 to 20 mA to be simulated.
]] SETPOINTS
]] S5 TESTING
] ANALOG INPUTS
] SIMULATION
SIMULATION:
OFF
SIMULATION ENABLED
FOR: 15 min
ANALOG INPUT:
OFF mA
]] SETPOINTS
]] S1 PQM SETUP
Range: OFF, ON
Range: 5 to 300, UNLIMITED
Step: 5 min
] TEST RELAYS & LEDS
]
] CURRENT/VOLTAGE
] SIMULATION
Range: 4.0 to 20.0, OFF
Step: 0.1 mA
] ANALOG OUTPUTS
] SIMULATION
MESSAGE
MESSAGE
MESSAGE
