GE Power Quality Meter Series User Manual

4-14 PQM Power Quality Meter GE Power Management
4.2 S1 PQM SETUP 4 PROGRAMMING
4
4.2.10 TRACE MEMORY
Figure 4–10: SETPOINTS PAGE 1 – PQM SETUP / TRACE MEMORY
]] SETPOINTS
]] S1 PQM SETUP
TRACE MEMORY USAGE:
1 x 36 cycles
]] SETPOINTS
]] S2 SYSTEM SETUP
SETPOINT
Range:1x36,2x18,3x12cycles
] EVENT RECORDER
]
] TRACE MEMORY
]
TRACE MEMORY TRIGGER
MODE: ONE SHOT
Ia OVERCURRENT TRIG
LEVEL: OFF % CT
Ib OVERCURRENT TRIG
LEVEL: OFF % CT
Ic OVERCURRENT TRIG
LEVEL: OFF % CT
In OVERCURRENT TRIG
LEVEL: OFF % CT
Va OVERVOLTAGE TRIG
LEVEL: OFF % NOMINAL
Vb OVERVOLTAGE TRIG
LEVEL: OFF % NOMINAL
Vc OVERVOLTAGE TRIG
LEVEL: OFF % NOMINAL
Va UNDERVOLTAGE TRIG
LEVEL: OFF % NOMINAL
Vb UNDERVOLTAGE TRIG
LEVEL: OFF % NOMINAL
Vc UNDERVOLTAGE TRIG
LEVEL: OFF % NOMINAL
SWITCH INPUT A TRIG:
OFF
SWITCH INPUT B TRIG:
OFF
SWITCH INPUT C TRIG:
OFF
SWITCH INPUT D TRIG:
OFF
Range: ONE SHOT, RETRIGGER
Range: 1 to 150; Step 1%
TRACE MEMORY TRIGGER
DELAY: 0 cycles
TRACE MEMORY TRIGGER
RELAY: OFF
Range: OFF, OPEN-TO-CLOSED,
CLOSED-TO-OPEN
Range: 0 to 30;
Step: 2 cycles
Range: OFF, AUX1,
AUX2, AUX3, ALARM
Range: 1 to 150; Step 1%
Range: 1 to 150; Step 1%
Range: 1 to 150; Step 1%
Range: 1 to 150; Step 1%
Range: 20 to 150; Step 1%
Range: 20 to 150; Step 1%
Range: 20 to 150; Step 1%
Range: 20 to 150; Step 1%
Range: 20 to 150; Step 1%
Range: OFF, OPEN-TO-CLOSED,
CLOSED-TO-OPEN
Range: OFF, OPEN-TO-CLOSED,
CLOSED-TO-OPEN
Range: OFF, OPEN-TO-CLOSED,
CLOSED-TO-OPEN
MESSAGE
MESSAGE
MESSAGE
