HEIDENHAIN ITNC 530 User Manual

HEIDENHAIN iTNC 530 139
3.4 Working with the file manager
Some functions, such as copying or erasing files, can not only be used
for individual files, but also for several files at once. To tag several files,
proceed as follows:
Move the highlight to the first file
To display the tagging functions, press the TAG soft
key
To tag a file, press the TAG FILE soft key
Move the highlight to the next file you wish to tag:
Only works via soft keys. Do not use the arrow keys!
To tag further files, press the TAG soft key, etc
To copy the tagged files, press the COPY TAG soft
key, or
Delete the tagged files by pressing the END soft key
to end the tagging functions, and then the DELETE
soft key to delete the tagged files

HEIDENHAIN ITNC 530 Specifications

General

Control Type	CNC
Look-ahead	Yes
Spindle control	Yes
Touch probe cycles	Yes
Operating voltage	24 V DC
Programming	Conversational and DIN/ISO programming
Interpolation	Linear, Circular, Helical
Data Interface	Ethernet, USB, RS-232
Memory	1 GB
Programming Language	HEIDENHAIN plain language
Operating Modes	Manual, Automatic, MDA
Software Options	Various software options available
