14.1 Switch-on, switch-off
14.1 Switch-on, switch-off
Switch-on
Switch on the power supply for TNC and machine. The TNC
automatically initiates the following dialog
The TNC memory is checked automatically.
TNC message that the power was interrupted—clear
the message.
The PLC program of the TNC is automatically compiled
Switch on external dc voltage. The TNC checks the
functioning of the EMERGENCY STOP circuit
Cross the reference points manually in the displayed
sequence: For each axis press the machine START
button, or
Cross the reference points in any sequence: Press
and hold the machine axis direction button for each
axis until the reference point has been traversed
Switch-on and crossing over the reference points can vary
depending on the machine tool. Refer to your machine
manual.
MEMORY TEST
POWER INTERRUPTED
COMPILE A PLC PROGRAM
RELAY EXTERNAL DC VOLTAGE MISSING
MANUAL OPERATION
TRAVERSE REFERENCE POINTS

HEIDENHAIN ITNC 530 Specifications

General

Control Type	CNC
Look-ahead	Yes
Spindle control	Yes
Touch probe cycles	Yes
Operating voltage	24 V DC
Programming	Conversational and DIN/ISO programming
Interpolation	Linear, Circular, Helical
Data Interface	Ethernet, USB, RS-232
Memory	1 GB
Programming Language	HEIDENHAIN plain language
Operating Modes	Manual, Automatic, MDA
Software Options	Various software options available
