546 Programming: Pallet Management
13.1 Pallet management
Selecting a pallet table
 Call the file manager in the Programming and Editing or Program
Run mode: Press the PGM MGT key
 Display all type .P files: Press the SELECT TYPE and SHOW .P soft
keys
 Select a pallet table with the arrow keys, or enter a new file name
to create a new table
 Confirm your entry with the ENT key
Exiting the pallet file
 Call the file manager: Press the PGM MGT key
 To select a different type of file, press the SELECT TYPE soft key
and the soft key for the desired file type, for example SHOW .H
 Select the desired file
Go to beginning of next line
Add the number of lines that can be entered at
the end of the table
Copy the highlighted field (2nd soft-key row)
Insert the copied field (2nd soft-key row)
Editing function Soft key
