HEIDENHAIN iTNC 530 275
7.1 DXF data processing (software option)
Opening a DXF file
Select the Programming and Editing operating mode
Call the file manager
In order to see the soft-key menu for selecting the file
type to be displayed, press the SELECT TYPE soft key
In order to show all DXF files, press the SHOW DXF
soft key
Select the directory in which the DXF file is saved
Select the desired DXF file, and load it with the ENT
key. The TNC starts the DXF converter and shows the
contents of the DXF file on the screen. The TNC
shows the layers in the left window, and the drawing
in the right window
Working with the DXF converter
The DXF converter runs as a separate application on the third desktop
of the TNC. This enables you to use the screen switchover key to
switch between the machine operating modes, the programming
modes and the DXF converter as desired. This is especially useful if
you want to insert contours or machining positions in a plain-language
program by copying through the clipboard.
A mouse is required to use the DXF converter. Operating
modes and functions as well as contours and machining
positions can only be selected with the mouse.
