HEIDENHAIN ITNC 530 User Manual

446 Programming: Special Functions
11.6 Adaptive Feed Control (AFC—software option)
Proceed as follows to select and, if required, edit the
<name>.H.AFC.DEP file:
 Select the Program Run, Full Sequence operating
mode
 Shift the soft-key row
 Select the table of AFC settings
 Make optimizations if required
You can also edit the <name>.H.AFC.DEP file in the Programming and
Editing mode of operation. If necessary, you can even delete a
machining step (entire line) there.
Note that the <name>.H.AFC.DEP file is locked against
editing as long as the NC program <name>.H is running. The
TNC then displays the data in the table in red.
The TNC removes the editing lock if one of the following
functions has been executed:
 M02
 M30
 END PGM
In order to edit the <name>.H.AFC.DEP file, you must first
set the file manager so that the TNC can display
dependent files (see "Configuring PGM MGT" on page
679).

HEIDENHAIN ITNC 530 Specifications

General

Control Type	CNC
Look-ahead	Yes
Spindle control	Yes
Touch probe cycles	Yes
Operating voltage	24 V DC
Programming	Conversational and DIN/ISO programming
Interpolation	Linear, Circular, Helical
Data Interface	Ethernet, USB, RS-232
Memory	1 GB
Programming Language	HEIDENHAIN plain language
Operating Modes	Manual, Automatic, MDA
Software Options	Various software options available
