No. Item Description
1~15: vfcID
1a to 8h: Network segment identifier of shared NIC
Add "v" to the end of line when using VF NIC.
(The contents of a display depend on the number of
installed controllers of NIC, and numbers of ports.)
Va to Vd: Network segment identifier of Virtual NIC
(7) Slot Host PciConfig
Displays equipped location of physical PCI devices
('—' are displayed when the virtual NIC are equipped)
"err" or "!" next to the slot display indicates that the
physical PCI device is blocked or hot removed.
LPAR PciConfig
Displays equipped location of logical PCI devices.
('—' are displayed when the virtual NIC are equipped)
"!" next to the slot display indicates that the physical PCI
device is hot removed.
(8) Seg.Bus.Dev.Fnc Host PciConfig
Displays PCI config address of physical NIC and virtual
NIC.
LPAR PciConfig
Displays Config address of logical PCI devices on the
LPAR.
(End character '*' of the PCI config address means that
the physical and logical PCI information are different)
PCI Device Assignment
The following functions are available in the PCI Device Assignment screen.
Operation by LPAR manager Screen
7-39
Hitachi Compute Blade 500 Series Logical partitioning manager User's Guide
