Huawei FusionModule800 Quick Guide

1
Item Specifications
Cabinet dimensions
(H x W x
D)/Reference net
weight
• IT cabinet: 2000 mm x 600 mm x 1350 mm/160 kg
• Converged Cabinet: 2000 mm x 600 mm x 1350 mm/410 kg
• Battery cabinet (deployed inside the aisle containment): 2000 mm x
600 mm x 1350 mm/160 kg
• Battery cabinet (deployed outside the aisle containment): 2000 mm
x 600 mm x 1100 mm/1200 mm/140 kg
• Network cabinet: 2000 mm x 800 mm x 1350 mm/160 kg
Indoor unit (with a
control unit)
dimensions (H x W x
D)/Net & gross
weight
• With water pump, heater, and humidifier: NetCol5000-A013: 486
mm x 442 mm x 800 mm/52.6 kg & 70 kg
• With water pump, but without heater and humidifier: NetCol5000-
A013: 486 mm x 442 mm x 800 mm/49.4 kg & 66.8 kg
Outdoor unit
dimensions (H x W x
D)/Net & gross
weight
• NetCol500-A018: 966 mm x 1057 mm x 339 mm/83 kg & 99 kg
• NetCol500-A020: 1327 mm x 966 mm x 320 mm/101 kg & 114 kg
• NetCol500-A021: 1350 mm x 1270 mm x 730 mm/205 kg & 235 kg
Bearing capacity
• Standard live load of the main equipment room: 8-12 kN/m² (If the
battery cabinet is placed inside the smart module, use the standard
live load of the main equipment room as a reference.)
• Suspended load of the main equipment room: 1.2 kN/m²
• Standard live load of the battery room: 16 kN/m²
Levelness Allowed deviation: 3/2000 mm
Equipment room
height
≥ 2.6 m
Equipment room area 8–30 m²
Door size Height > 2.2 m; width > 0.9 m
Elevator
Elevator bearing capacity > 1.5 t
Elevator internal size: height > 2.4 m, depth > 1.4 m
Elevator door size: height > 2.2 m; width > 0.9 m
Power supply 380 V AC/400 V AC/415 V AC, 3 Ph + N, 50 Hz/60 Hz
Floor drain DN50 or larger, made of cast iron or stainless steel
Grounding
A general ground bar is configured in the Converged Cabinet. The
general ground point in each cabinet connects to the general ground
bar in the Converged Cabinet. The general ground bar in the
Converged Cabinet connects to the floor ground bar or collective
ground bar.
Water port
Condensate drain outlet: for draining condensate from the smart
cooling product.
Humidifier water pipe port: Connects to external water pipes to supply
water to the humidifier.
Overview
Copyright © Huawei Digital Power Technologies Co., Ltd.
2023. All rights reserved.
