Huawei FusionModule800 Quick Guide

37
13.14
(Optional) Installing an In-Room Double Door Magnetic Lock
1. Fold the cutout template 90 degrees,
mark mounting holes, and drill holes.
2. Remove the hoisting strip.
(1) Door
frame
(2) Cutout
template
(3) Door
panel
3. Secure the hoisting strip.
4. Route cables and secure the
magnetic lock.
5. Install the magnet.
6. (Optional) Adjust the magnet.
Pay attention to the direction of the hoisting
strip, and ensure that the bulging surface of
the magnetic lock faces the magnet.
Rubber pad
13.15
(Optional) Installing an In-Room Single Door Magnetic Lock
1. Fold the cutout template 90 degrees, mark
mounting holes, and drill holes.
(1) Door frame (2) Cutout template (3) Door panel
2. Remove the hoisting strip.
