4. Connect the communications cables to the T/H sensors.
13.8
Installing T/H Sensors (33010516)
ECC800-Pro
T/H sensor 2
Temperature sensor
Installing one T/H sensor when only one NetCol is configured
• The figure is for reference only. Install the devices based on site requirements.
• The NetCol remote T/H sensors are attached to the leftmost and rightmost IT cabinets near
aisle columns.
A: Position for installing the T/H sensor for the NetCol at the bottom of the Converged Cabinet, 28 U
T/H sensor 1
To Next Page
