6: ALLOCATION NUMBERS
6-6 « FC4A MICROSMART USER’S MANUAL »
Operand Allocation Numbers for Data Link Master Station
Note: When any slave stations are not connected, master station data registers which are assigned to the vacant slave sta-
tions can be used as ordinary data registers.
Operand Allocation Numbers for Data Link Slave Station
Note: Slave station data registers D912 through D1271 and D8070 through D8099 can be used as ordinary data registers.
Slave Station Number
Allocation Number
Transmit Data
to Slave Station
Receive Data
from Slave Station
Data Link
Communication Error
Slave Station 1 D900-D905 D906-D911 D8069
Slave Station 2 D912-D917 D918-D923 D8070
Slave Station 3 D924-D929 D930-D935 D8071
Slave Station 4 D936-D941 D942-D947 D8072
Slave Station 5 D948-D953 D954-D959 D8073
Slave Station 6 D960-D965 D966-D971 D8074
Slave Station 7 D972-D977 D978-D983 D8075
Slave Station 8 D984-D989 D990-D995 D8076
Slave Station 9 D996-D1001 D1002-D1007 D8077
Slave Station 10 D1008-D1013 D1014-D1019 D8078
Slave Station 11 D1020-D1025 D1026-D1031 D8079
Slave Station 12 D1032-D1037 D1038-D1043 D8080
Slave Station 13 D1044-D1049 D1050-D1055 D8081
Slave Station 14 D1056-D1061 D1062-D1067 D8082
Slave Station 15 D1068-D1073 D1074-D1079 D8083
Slave Station 16 D1080-D1085 D1086-D1091 D8084
Slave Station 17 D1092-D1097 D1098-D1103 D8085
Slave Station 18 D1104-D1109 D1110-D1115 D8086
Slave Station 19 D1116-D1121 D1122-D1127 D8087
Slave Station 20 D1128-D1133 D1134-D1139 D8088
Slave Station 21 D1140-D1145 D1146-D1151 D8089
Slave Station 22 D1152-D1157 D1158-D1163 D8090
Slave Station 23 D1164-D1169 D1170-D1175 D8091
Slave Station 24 D1176-D1181 D1182-D1187 D8092
Slave Station 25 D1188-D1193 D1194-D1199 D8093
Slave Station 26 D1200-D1205 D1206-D1211 D8094
Slave Station 27 D1212-D1217 D1218-D1223 D8095
Slave Station 28 D1224-D1229 D1230-D1235 D8096
Slave Station 29 D1236-D1241 D1242-D1247 D8097
Slave Station 30 D1248-D1253 D1254-D1259 D8098
Slave Station 31 D1260-D1265 D1266-D1271 D8099
Data
Allocation Number
Transmit Data
to Master Station
Receive Data
from Master Station
Data Link
Communication Error
Slave Station Data D900-D905 D906-D911 D8069
