IDEC FC4A-C16R2 User Manual

8: ADVANCED INSTRUCTIONS
« FC4A MICROSMART USER’S MANUAL » 8-3
Advanced Instruction Applicable CPU Modules
Applicable advanced instructions depend on the type of CPU modules as listed in the table below.
Group Symbol
All-in-One Type CPU Modules Slim Type CPU Modules
FC4A-C10R2
FC4A-C10R2C
FC4A-C16R2
FC4A-C16R2C
FC4A-C24R2
FC4A-C24R2C
FC4A-D20K3
FC4A-D20S3
FC4A-D20RK1
FC4A-D20RS1
FC4A-D40K3
FC4A-D40S3
NOP NOP X X X X X
Move
MOV X X X X X
MOVN X X X X X
IMOV X X X X X
IMOVN X X X X X
BMOV X
IBMV X
IBMVN X
Data Comparison
CMP= X X X X X
CMP<> X X X X X
CMP< X X X X X
CMP> X X X X X
CMP<= X X X X X
CMP>= X X X X X
ICMP>= X
Binary Arithmetic
ADD X X X X X
SUB X X X X X
MUL X X X X X
DIV X X X X X
ROOT X X X X X
Boolean
Computation
ANDW X X X X X
ORW XXXXX
XORW X X X X X
Shift and Rotate
SFTL X X X X X
SFTR X X X X X
BCDLS X
WSFT X
ROTL X X X X X
ROTR X X X X X
Data Conversion
HTOB X X X X X
BTOH X X X X X
HTOA X X X X X
ATOH X X X X X
BTOA X X X X X
ATOB X X X X X
ENCO X
DECO X
BCNT X
ALT X
