3: I
NSTALLATION
AND
W
IRING
« FC4A M
ICRO
S
MART
U
SER
’
S
M
ANUAL
»
3-13
Input Wiring
DC Source Input
DC Sink Input
Caution
•
Separate the input wiring from the output line, po
wer line, and motor line.
•
Use proper wires for input wiring.
All-in-one type CPU modules:
UL1015
A
WG22 or UL1007
A
WG18
Slim type CPU and I/O modules:
UL1015
A
WG22
COM
COM
0
1
2
3
4
5
6
7
DC.IN
01
234567
+
–
+
–
24V DC
2-wire Sensor
NPN
COM
COM
0
1
2
3
4
5
6
7
DC.IN
01
234567
+
–
+
–
24V DC
2-wire Sensor
PNP
106
108
