8: A
DVANCED
I
NSTRUCTIONS
« FC4A M
ICRO
S
MART
U
SER
’
S
M
ANUAL
»
8-7
NOP (No Operation)
Details of all other adv
anced instructions are described in the following chapters.
No operation is executed by the NOP instr
uction.
The NOP instr
uction may ser
ve as a place holder. Another use would be to add a delay to the CPU scan
time, in order to simulate communication with a machine or application, for debugging purposes.
The NOP instr
uction does not requir
e an input and operand.
NOP
216
218
