2: M
ODULE
S
PECIFICATIONS
2-68
« FC4A M
ICRO
S
MART
U
SER
’
S
M
ANUAL
»
Dimensions
All
MicroSmar
t
modules hav
e the same profile for consistent mounting on a DIN rail.
CPU Modules
FC4A-C10R2, FC4A-C10R2C, FC4A-C16R2, FC4A-C16R2C
FC4A-C24R2, FC4A-C24R2C
80.0
90.0
4.5*
70.0
*8.5 mm when the clamp is pulled out.
*8.5 mm when the clamp is pulled out.
95.0
70.0
90.0
4.5*
All dimensions in mm.
87
89
