Using Eagle Research Field Manager to change the XARTU
corrector settings
1. Open the Eagle Research Field Manager from
the Start menu or the desktop shortcut.
2. Click Connect on the upper left corner of the
Field Manager window.
3. Select the following parameters:
• Connection Type: Direct
• Communications Port: Enter your computer's port number.
• Baud Rate: Enter the baud rate for the XARTU-1 corrector.
4. Verify that the time and station name are correct.
5. Click View/Config..
Click OK
6. Click the Setup Parameters tab at the bottom of the parameters window.
The Meter Setup and Accumulation Multipliers
window opens. Set up the meter and
accumulation multipliers as appropriate for your
installation.
7. Enable K2 (4, 5, 6) and set additional
parameters are required in the Uncorrected
Pulse Output Setup section in the lower right of
the window.
Specific Meter Manufacturer Installation
100G Series Gas ERT Module Installation Guide, Remote Mount TDC-0824-017 25
Proprietary and Confidential
