(1) Adjusting Screw (2) Lock Nut
ADJUSTING FRONT AXLE PIVOT
PIN (AD)
If the front axle pivot pin adjustment
is not correct, front wheel vibration
can occur.
ADJUSTING PROCEDURE
Loosen the lock nut, tighten the ad-
justing screw all the way, and then
loosen the screw by 1/6 turn. Re-
tighten the lock nut.
td2O730A
Improper adjustment of the valve clea-
rance can reduce the performance
and / or damage the engine. This adju-
stment should only be preformed by a
certied KIOTI dealer.
ADJUSTING ENGINE VALVE
CLEARANCE (AE)
If the air cleaner is not in a good con-
dition, the lifetime of the engine can
be shortened, excessive soot can be
produced, and the engine power can
be deteriorated. Therefore, the lter
should be inspected frequently. Its
replacement interval can be chan-
ged according to driving conditions.
Replace the filter according to the
following procedure:
1. Open the hood and check the suc-
tion hose and air cleaner housing for
damage.
REPLACING AIR CLEANER FILTER
(AF)
(1) Filter (2) Dust Cap
(3) Evacuator Valve
td2O721A
