REAR TIRE SPECS AND WHEEL
BOLT/NUT TORQUE
Tire size (Agri)
13.6-24 / 6PR
WARNING
Use tires approved by KIOTI only.
Assemble the tire as shown in
the gure.
Contact your local KIOTI Dea
-
ler if it is necessary to change
the tire specication or instal-
lation method.
•
•
•
Tightening torque of wheel bolt (Nut)
196~225 N·m
144.6~166.3 lbf-ft
20 ~ 23 kgf·m
td2O459A
(1) Additional Front Weight
If the loader is not installed, attach
a weight to the front frame of the
tractor as a safety measure.
If a heavy implement is installed at
the rear or when towing a heavy trai-
ler, the front wheels may be lifted.
Add sufcient weight to keep steera-
bility and to prevent rollover.
If sufcient weight, such as front loa-
der, is applied to the front wheels,
remove the extra front weight.
ADDITIONAL WEIGHT (OPTION)
ADDITIONAL FRONT WEIGHT
If the front tires are excessively loa
-
ded, it becomes hard to steer the
tractor, the tires can be worn faster
and the durability of the front axle
can be deteriorated.
To Next Page
