(1) Fuse Box
td2O735A
BODY FUSE (AN)
Fuses protect the tractor electrical
system from potential damage.
A blown fuse indicates that there is
an overload or short somewhere in
the electrical system.
The fuse panel is located in the right
section of the engine compartment.
td2O736b
h11O655A
There are marks for the fuse capacity
and location on the cover of the fuse
panel. Replace the fuse according to
the following procedure:
1. Turn the key switch to the “OFF”
position and turn off all the electri-
cal devices.
2. Open the fuse box cover and che-
ck the fuse in question using fuse
tongs.
3. If the fuse is blown, replace it with
a new fuse with same capacity.
Make sure it is rmly installed.
4. Install the fuse box cover.
Standard
CRDI type
