The switch is used to set the PTO
rpm. With the PTO cruise button set
in the ON position, pressing the SET
(-) button turns on this lamp.
CRUISE PTO WARNING LAMP
td2O420A
QUICK-TURN INDICATOR
(IF APPLICABLE)
This indicates activation of the quick-
turn function.
This function is activated only when
the driving mode selection switch is
in the “QT” position and the steering
angle of the front wheels is over 35
˚. This function is used to reduce the
turning radius by increasing the rota-
tion speed of the outer front wheel,
increasing the turning performance
in the 4WD operation.
td2O421A
WARNING
In the warning level 3 (CEL lamp
ON), both manual and automa-
tic regeneration processes can-
not be performed.
When the DPF warning lamp co-
mes on, make sure to perform the
manual regeneration as the active
regeneration cannot be performed.
Enabling condition for manual
regeneration
- Clutch engaged
- Brake ON
- Engine rpm Idle state
If any of the above conditions is
not met during regeneration, the
regeneration mode is deactivated.
Other general operation can-
not be performed during the
manual regeneration process.
During regeneration, the engi-
ne speed is maintained
- at 1,500 rpm for 10 minutes
- at 2,600 rpm for 25 minutes
- at 1,600 rpm for 3 minutes
•
•
•
•
•
