40
3�2 Operation Mode
This section describes operation mode of DRYPRO MODEL 873.
3�2�1
Current Status Display
Tray information and the current status are displayed in the display window of the operation panel.
Status information display area
Job information display area
Regular maintenance information display area
Tray information display area
Status Display
The status of the main unit is shown.
Status Message Meaning
Warming up. XX minutes to Ready The machine is warming up.
Ready The machine is ready to print.
Printing The machine is printing.
Film Empty None of the trays have film.
CXXX Warning
(where "XXX" are alphanumeric characters
consisting of 0 - 9 and A - F.)
Error status (A minor error has occurred. No action is needed.) If
action is needed, the display changes.
Clean the roller /Press the 'Service/Enter'
(The above messages are displayed alter
-
nately.)
Roller Cleaning must be performed.
Filter exchange/Open the front cover
(The above messages are displayed alter
-
nately.)
The filter must be replaced.
Perform Prev. maintenance/Please contact
the Service Center
(The above messages are displayed alter
-
nately.)
Regular maintenance must be performed.
Perform Calibration This is displayed when the main unit must be calibrated, after film
has been loaded, or when a density read error has been detected.
(This is cleared after calibration is performed.)
Select tray This is displayed when a tray must be selected for printing QC pat
-
terns or a calibration sheet.
Not connected to PC/Please refer to the man
-
ual
(The above messages are displayed alter
-
nately.)
The connection with PC could not be established. Refer to
“4.1 Need Help?” (page 78).
Job Information
The amount of film queued for printing is displayed.
Icon Name Meaning
Output Queue Number of jobs queued for printing
Number of Prints Total number of prints for queued jobs. (The actual number of
sheets to be printed.)
To Next Page
