TECHNICAL DATA 23
161
23.2 Engine tightening torques
Screw, damping plate EJOT ALtracs
®
M6x14 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, retaining bracket, valve
cover, rear
EJOT
®
M6x12 8 Nm (5.9 lbf ft)
Hose clip, intake flange M4 1.5 Nm (1.11 lbf ft)
Oil nozzle M5 2 Nm (1.5 lbf ft)
Loctite
®
243™
Remaining engine screws M5 6 Nm (4.4 lbf ft)
Screw, bearing retainer M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, bearing shells retaining
bracket
M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, cable duct on the engine
fixing arm
M5 5 Nm (3.7 lbf ft)
Screw, crankshaft speed sensor M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, engine oil level viewer M5 4 Nm (3 lbf ft)
Loctite
®
243™
Screw, gear position sensor M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, oil filter cover M5 6 Nm (4.4 lbf ft)
Screw, resonator M5 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, shift shaft sensor M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Bleeder screw, cylinder head M6 6 Nm (4.4 lbf ft)
Bleeder screw, water pump cover M6 10 Nm (7.4 lbf ft)
Coolant connection screw on the
cylinder head
M6 8 Nm (5.9 lbf ft)
Loctite
®
243™
Freewheel ring bolt M6 – 10.9 15 Nm (11.1 lbf ft)
Loctite
®
648™
Nut, cylinder head M6 8 Nm (5.9 lbf ft)
Remaining engine screws M6 10 Nm (7.4 lbf ft)
Screw, alternator cover M6 10 Nm (7.4 lbf ft)
Screw, camshaft bearing support M6 – 10.9 10 Nm (7.4 lbf ft)
Screw, clutch cover M6 10 Nm (7.4 lbf ft)
Screw, clutch spring M6 12 Nm (8.9 lbf ft)
Screw, engine case M6x60 10 Nm (7.4 lbf ft)
Screw, engine case M6x80 10 Nm (7.4 lbf ft)
Screw, engine case M6x90 10 Nm (7.4 lbf ft)
Screw, guide rail M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, ignition coil M6 8 Nm (5.9 lbf ft)
Screw, kickstarter gear support M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, locking lever M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
