23 TECHNICAL DATA
166
23.7 Fork
23.7.1 SUPER DUKE R
Fork article number 14.18.8T.22
Fork WP SuspensionAPEX 5548
Compression damping
Comfort 21 clicks
Standard 15 clicks
Sport 7 clicks
Full payload 7 clicks
Rebound damping
Comfort 21 clicks
Standard 15 clicks
Sport 7 clicks
Full payload 7 clicks
Spring length with preload spacer(s) 303 mm (11.93 in)
Spring rate
Soft 8.5 N/mm (48.5 lb/in)
Medium (standard) 9 N/mm (51 lb/in)
Hard 9.5 N/mm (54.2 lb/in)
Fork length 753 mm (29.65 in)
Fork oil per fork leg 615 ± 15 ml (20.79
± 0.51 fl. oz.)
Fork oil (SAE 4) (48601166S1)
( p. 176)
23.7.2 SUPER DUKE RR
Fork article number 0617C101U402200
Fork WP Suspension APEX PRO 7548
Compression damping
Street 24 clicks
Sport 20 clicks
Race course 17 clicks
Rebound damping
Street 17 clicks
Sport 15 clicks
Race course 15 clicks
Spring length with preload spacer(s) 264 mm (10.39 in)
Spring rate
Weight of rider: 55 … 65 kg (121 … 143 lb.) 8 N/mm (46 lb/in)
Weight of rider: 65 … 75 kg (143 … 165 lb.) 8.5 N/mm (48.5 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 9 N/mm (51 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 9.5 N/mm (54.2 lb/in)
Weight of rider: 95 … 105 kg (209 … 231 lb.) 10 N/mm (57 lb/in)
Fork length 765 mm (30.12 in)
Oil capacity, external mechanism 550 ml (18.6 fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 176)
