CONTROLS 6
17
6.6 Menu buttons
S03881-11
The menu buttons are fitted in the middle of the left combination
switch.
The menu buttons are used to control the display on the combina-
tion instrument.
Button
1
is the UP button.
Button
2
is the RIGHT button.
Button
3
is the DOWN button.
Button
4
is the LEFT button.
Button
5
is the SET button.
Button
6
is the BACK button.
6.7 Turn signal switch
S03881-12
Turn signal switch
1
is fitted on the combination switch on the
left.
Possible states
Turn signal off – Turn signal switch pushed toward the
switch housing.
Left turn signal, on – Turn signal switch pressed to
the left. The turn signal switch returns automatically
to the central position after use.
Right turn signal, on – Turn signal switch pressed to
the right. The turn signal switch returns automatically
to the central position after use.
Info
An automatic turn signal switch-off function (ATIR) is avail-
able as a software feature.
The ATIR function uses a time and distance counter.
If the turn signal has been on for at least 10 seconds and
150 meters of riding distance, the turn signal is switched
off.
If the vehicle is stationary, both counters are stopped.
If the turn signal switch is reactivated, both counters are
reset.
6.8 Horn button
S03881-13
Horn button
1
is fitted on the left side of the handlebar.
Possible states
• The horn button is in the basic position
• The horn button is pressed – The horn is operated in this
position.
