KTM 1290 SUPER DUKE R 2021 User Manual

COMBINATION INSTRUMENT 7
27
Info
The malfunction indicator lamp always lights up as long as
the engine is not running. If the engine is running and the
malfunction indicator lamp lights up, stop (taking care not
to endanger yourself or other road users in the process) and
contact an authorized KTM workshop.
The oil pressure warning lamp always lights up as long as
the engine is not running. If the engine is running and the
oil pressure warning lamp lights up, stop immediately (tak-
ing care not to endanger yourself or other road users in the
process) and switch off the engine.
The ABS warning lamp and TC indicator lamp light up until
a speed of approx. 6 km/h (approx. 4 mph) or more has
been reached.
7.3 Day-night mode
S03748-01
Day mode is shown in a bright color.
S03749-01
Night mode is shown in a dark color.
Info
The ambient light sensor in the combination instrument
measures the brightness of the environment and automat-
ically switches the display to day or night mode. The dis-
play is brightened, darkened or switched to the other mode
depending on the brightness measured by the ambient light
sensor.
In the Display Theme menu, the display mode can be
changed manually between AUTOMATICand NIGHT.

KTM 1290 SUPER DUKE R 2021 Specifications

General

Displacement	1301 cc
Transmission	6-speed
Rear Suspension	WP APEX monoshock, fully adjustable
Seat Height	835 mm
Fuel Tank Capacity	16 liters
Dry Weight	189 kg
Bore x Stroke	108 mm x 71 mm
Compression Ratio	13.5:1
Fuel System	Electronic fuel injection
Lubrication	Forced oil lubrication with 3 oil pumps
Wheelbase	1482 mm
Traction Control	MTC (Motorcycle Traction Control), lean-angle sensitive
Engine Type	V-Twin, 4-stroke
Power	180 hp
Torque	140 Nm @ 8000 rpm
Frame	Chromium-Molybdenum steel frame, powder coated
Front Suspension	WP APEX 48
Front Brake	320 mm discs
Rear Brake	Brembo two-piston caliper, 240 mm disc
Clutch	PASC slipper clutch, hydraulically actuated
ABS	Bosch 9.1 MP (incl. Cornering ABS and Supermoto mode)
