KTM 1290 SUPER DUKE R 2021 User Manual

TECHNICAL DATA 23
163
Screw, conrod bearing M10x1 Step 1
25 Nm (18.4 lbf ft)
Step 2
30 Nm (22.1 lbf ft)
Step 3
90°
Screw, unlocking of timing chain
tensioner
M10x1 8 Nm (5.9 lbf ft)
Spark plug outside M10x1 11 Nm (8.1 lbf ft)
Coolant temperature sensor M10x1.25 12 Nm (8.9 lbf ft)
Cylinder head screw M11x1.5 Tightening sequence:
Using a crisscross pattern
Step 1
15 Nm (11.1 lbf ft)
Step 2
30 Nm (22.1 lbf ft)
Step 3
90°
Step 4
90°
Lubricated with engine oil
Screw, shock absorber bell crank M12 80 Nm (59 lbf ft)
Rotor screw M12x1.5 115 Nm (84.8 lbf ft)
Spark plug inside M12x1.5 18 Nm (13.3 lbf ft)
Nut of engine sprocket M20x1.5 100 Nm (73.8 lbf ft)
Loctite
®
243™
Oil drain plug M20x1.5 20 Nm (14.8 lbf ft)
Nut, inner clutch hub M22x1.5 140 Nm (103.3 lbf ft)
Plug, timing-chain tensioner M24x1.5 25 Nm (18.4 lbf ft)
Screw plug, alternator cover M24x1.5 8 Nm (5.9 lbf ft)
Nut, primary gear wheel M33LHx1.5 130 Nm (95.9 lbf ft)
Loctite
®
243™
23.3 Capacities
23.3.1 Engine oil
Engine oil
Ambient temperature: ≥ 0 °C
(≥ 32 °F)
3.50 l (3.7 qt.) Engine oil (SAE 10W/50)
( p. 175)
Engine oil
Ambient temperature: < 0 °C
(< 32 °F)
Engine oil (SAE 5W/40) ( p. 176)
23.3.2 Coolant
Coolant 3.20 l (3.38 qt.) Coolant ( p. 175)

KTM 1290 SUPER DUKE R 2021 Specifications

General

Displacement	1301 cc
Transmission	6-speed
Rear Suspension	WP APEX monoshock, fully adjustable
Seat Height	835 mm
Fuel Tank Capacity	16 liters
Dry Weight	189 kg
Bore x Stroke	108 mm x 71 mm
Compression Ratio	13.5:1
Fuel System	Electronic fuel injection
Lubrication	Forced oil lubrication with 3 oil pumps
Wheelbase	1482 mm
Traction Control	MTC (Motorcycle Traction Control), lean-angle sensitive
Engine Type	V-Twin, 4-stroke
Power	180 hp
Torque	140 Nm @ 8000 rpm
Frame	Chromium-Molybdenum steel frame, powder coated
Front Suspension	WP APEX 48
Front Brake	320 mm discs
Rear Brake	Brembo two-piston caliper, 240 mm disc
Clutch	PASC slipper clutch, hydraulically actuated
ABS	Bosch 9.1 MP (incl. Cornering ABS and Supermoto mode)
