7 COMBINATION INSTRUMENT
30
TC indicator lamp lights up/flashes yellow – The MTC ( p. 146) is not active, is currently
intervening or a Launch Control Start is being executed. The TC indicator lamp also lights up
if a malfunction is detected. Contact an authorized KTM workshop. The TC indicator lamp
flashes if the motorcycle traction control actively engages.
The oil pressure warning lamp lights up red – The oil pressure is too low. Stop immediately,
taking care not to endanger yourself or other road users in the process, and switch off the
engine.
The cruise control system indicator lamp lights up yellow – The cruise control system function
is switched on, but cruise control is not activated.
The cruise control system indicator lamp lights up green – The cruise control system function
is switched on and cruise control is activated.
Malfunction indicator lamp lights up yellow – The OBD has detected a malfunction in the
vehicle electronics.
The right turn signal indicator lamp flashes green with a steady rhythmic flash – The right turn
signal is switched on.
7.7 Display
S03766-10
Info
The figure shows the start screen of the combination instrument. If the menu is opened, the speed is still
displayed.
1
Tachometer
1
Shift warning light ( p. 34)
The shift warning light is integrated in the tachometer display.
2
Speed
3
Unit for the speedometer
4
Fuel level display ( p. 37)
