IMPLEMENT LIMITATIONS
IMPLEMENT LIMITATION TABLES
IMPORTANT :
The Kubota tractor has been thoroughly tested for proper performance with implements sold or approved by
Kubota. Do not use the following implements:
• Implements that are not sold or approved by Kubota
• Implements that exceed the maximum specifications listed in the following table
• Implements that are otherwise unfit for use with the Kubota tractor
Preceding implements may result in malfunctions or failures of the tractor, damage to other property, and
injury to the operator or others.
NOTE :
• Kubota does not cover any malfunctions or failures of the tractor resulting from use with improper
implements by the warranty.
Model L3302, L3902
Maximum width of tread with farm tires
Front
1095 mm
(43.1 in.)
Rear
1290 mm
(50.8 in.)
Lower link end maximum loading weight (W0)
900 kg
(1985 lbs.)
Actual figures
Implement weight (W1) and/or size As in Implement weight list
Maximum drawbar load (W2)
330 kg
(730 lbs.)
Maximum capacity of trailer loading
weight (W3)
2300 kg
(5070 lbs.)
W0
Lower link end maximum hydraulic lifting capacity weight
W1
Implement weight. The weight of the implement that can be put on the lower link
W2
Maximum drawbar load
W3
Trailer loading weight. The maximum loading weight for trailer with trailer's weight
NOTE :
• Implement size may vary depending on soil conditions where you operate the machine.
• Strictly follow the instructions outlined in the operator’s manual of the mounted or trailed machinery or
trailer, and do not operate the combination tractor-machine or tractor-trailer unless all instructions have
been followed.
• When you use the forestry application, there are following hazards:
– Toppling trees, primarily in the case of when a rear-mounted-tree grab crane is mounted at the rear of
the tractor
