6. Tachometer
The tachometer gives readings for the engine speed
and PTO-shaft speed.
The tachometer indicates the engine speed and the
location of 540 PTO-shaft speed on the dial.
(1) Tachometer (A) Engine revolution
(B) PTO (540 rpm)
7. CCV freezing warning system
WARNING
To avoid personal injury or death:
• Do not draw out the engine oil dipstick
immediately after the warning indicator has
come on. Allow engine to cool sufficiently
before drawing out the engine oil dipstick.
Otherwise the hot engine oil may spout and
make burn.
If the CCV drain hose freezes, the engine warning
indicator starts flashing, the error code (P1C09)
appears in the hour meter, and the buzzer starts
sounding continuously.
IMPORTANT :
• If the CCV freezing warning system is activated,
stop the engine and consult your local Kubota
Dealer immediately.
Otherwise the engine oil may spout and in the
worst case the engine is damaged then needs
to replaced.
• Before and after the cold season, check the
terminals, pressure switch, and others. If any
damage or corrosion are found, do not use the
machine and consult your local Kubota Dealer
for repair request.
(See Checking the CCV pressure switch on
page 126)
(1) Engine warning indicator
(2) Hour meter
PARKING THE TRACTOR
When parking the tractor, be sure to set the parking
brake.
WARNING
To avoid personal injury or death:
Before dismounting the tractor, follow the
following:
1. Always set the parking brake and lower all
implements to the ground.
Leaving the transmission in gear with the
engine stopped will not prevent the tractor with
HST transmission from rolling.
2. Stop the engine and remove the starter key.
Before getting off the tractor, perform the proper
procedure.
CHECK DURING DRIVING OPERATING THE TRACTOR
