KYMCO Super 8 50 Service Manual

9. DRIVE AND DRIVEN PULLEYS
9-8
Super 8 50
Measure the clutch lining thickness.
Service Limit: 1.5mm replace if below
CLUTCH/DRIVEN PULLEY
DISASSEMBLY
Hold the clutch/driven pulley assembly with
the clutch spring compressor.
Clutch Spring Compressor
Set the clutch spring compressor in a vise
and remove the clutch drive plate nut.
Loosen the clutch spring compressor and
disassemble the clutch/driven pulley
assembly.
Remove the seal collar.
Clutch/Driven Pulley
Clutch Spring Compressor
Special
Be sure to use a clutch spring compressor
to avoid spring damage.
＊

KYMCO Super 8 50 Specifications

General

Displacement	49.5 cc
Fuel System	Carburetor
Ignition	CDI
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70-12
Rear Tire	130/70-12
Cooling System	Air
Transmission	CVT Automatic
Seat Height	780 mm
Wheelbase	1, 280 mm
